Radar for distance measurement
IDR-2050 – Radar sensor
| Product family: | 60GHz distance radar |
|---|---|
| Applications: | Level measurement, collision protection, parking space occupancy, distance control, pre-crash assistance system |
| Functions: | Distance, presence, speed, direction of movement |
The 60 GHz radar system offers precise distance measurement of stationary and moving targets. Its compact design allows for easy integration into standard enclosures. The focused radar beam and functionality are specifically tailored to two areas of industrial distance measurement: non-contact level detection and collision avoidance. The IDR-2050 operates reliably in harsh or demanding industrial environments and functions equally well indoors and outdoors. The sensor’s signal output is user-adjustable, allowing for features such as limiting the range or filtering results based on signal strength.
PRODUCT HIGHLIGHTS
- Continuous distance measurement with millimeter accuracy
- Compact design for easy integration into housing systems
- Output of distance, speed, direction of movement, and signal strength of targets via UART
- Configurable detection range
- Narrow beamwidth (azimuth and elevation)
- Extreme temperatures, humidity, foaming, dirt or dust do not affect performance.
- Detects a wide variety of materials (liquids, bulk materials, powders)
TECHNICAL FEATURES
| Frequency: | FMCW radar & operates in the range of 62 GHz to 64 GHz |
|---|---|
| System level: | Contains a digital processing unit; outputs a target list via UART. |
| Measurement: | Distance and speed of stationary or moving objects (up to approx. 50 km/h) |
| Reach: | approximately 0 to 10m |
| Detection range: | 8°x8° |
| External dimensions: | 43.6×43.6×21.4mm |
| Approvals & Certification: | Available on request |
| Documents & Programs: | Software package, quick start guide |
